If you are you intrested in being a part of this project or would like some more infornmation you can contact the Crew Chief Claude Sherwood by e-mail at arrow@torontoaerospacemuseum.com
Arrow Links:
Pictures of The Arrow | Great Arrow Page Hosted by Discovery Channel
Critics say "BEST ARROW SITE" | Good Arrow Page Created By - Michael Kostiuk
| Specification | Arrow 1 | Arrow 2 |
|---|---|---|
| Wingspan | 50'-0" (15.24 m) | 50'-0" (15.24 m) |
| Overall Length | 77'-9.65" (23.715 m) | 76'-9.65" (23.41 m) |
| Height | 21'-3" (6.477 m) | 21'-3" (6.477 m) |
| Engine | P&W J75-P-3 (RL201) and J75-P-5 | Orenda PS-13 Iroquois |
| Dry Thrust | 12 500lb (55.6 kN) static (J75) | 19 250lb (85.6 kN) static (Iroquois) |
| Wet Thrust | 18 500lb (82.3 kN) static (J75) | 26 000lb (115.7 kN) static (Iroquois) |
| Total Fuel | 2897 Imp. Gal. (13170 L) | 2897 Imp. Gal. (13170 L) |
| Usable Fuel | 2508 Imp. Gal. (11401.6 L) | 2509 Imp. Gal. (11406.1 L) |
| External Fuel | None | 500 Imp. Gal. (2273 L) available (external) |
| Crew | 2 (pilot/radar operator) | 2 (pilot/radar operator) |
| Armament | None | Multiple configurations available |
