From early optical cards through to electronic patterns.
These examples were all made with TCMaker from Oodletuz!
| Optical cards | |
|
|
| BBC Angel wing 405/NTSC colour tuning signal | |
| Electronic | Many of these are varients of the Philips PM5544, FuBK, or Toolcraft-Goodwood products |
|
|
| TGRT Ankara (2 grey blocks I couldn't make out). | Argentina |
|
|
| Melbourne's ATV0 - apparently their own design. | BBC Satellite test pattern. |
|
|
| China | Former Czech republic |
|
|
| Former East Germany (variant of Russian TSS) | EBU Bar |
|
|
| EMTV Papua New Guinea | ITV (UK) ETP-1, rectangular shape wasn't liked. |
|
|
| FubK card - former West Germany | Italy - looks like it's based on the FubK |
|
|
| Italy again, this one looks to be based on the PM5544 | Leningrad - named after the Russian TV studio in Leningrad |
|
|
| Program Line Up Generating Equipment (PLUGE) | PM5544 as used by ABC TV in Australia |
|
|
| Square PM5544 used by Dubai in the Emirates | TVE Spain |
|
|
| I think this what the Toolcraft Goodwood looks like | Toolcraft Goodwood from NRN11 Australia |
|
|
| Veneta - Looks like a Toolcraft-Goodwood | Veneto - '5544 based. |
Written by Wenlock
